52. M31, Andromeda Galaxy (Ανδρομεδη)

Distance: 2.54 million ly
App. Magnitude: 3.4
App. Dimensions: 190'x60' (cp. field of view 143'x96')

Notes: The is the first image with the William Optics F110 APO. The image appears to capture more of the disk than we saw in the M31 taken with the 80mm. We could make the image more dramatic by pushing the color saturation and contrast, but that would produce a grainier image and a magenta core. We see some red flare around the bright stars in the lower right, but in general we do not see the blue rings that we saw with the doublet lens. This image suffers a lot from the haze produced by the American Fire in Placer County. It appears to give it a reddish color and the image is less bright than it should be with two hours of exposure. Zoom in/out with ⌘↑(+/-) (Mac), ctrl (+/-) (PC).

Location: Nevada City, CA
Date: September 6, 2013
Scope: William Optics F110 APO Triplet, no field flattener
Mount: CGEM
Guide scope: Orion 80mm x 400 mm ShortTube
Guide camera: Orion Starshoot
Guide program: PHD Guiding
Camera: Canon T1i, IR filter mod by Hap Griffin
ISO: 800
Exposures: 40 at 3 min, 65°F at start each, darks: 20 at 66°F at start, biases: none, flats: none
Processing software: Nebulosity, Photoshop
Processing: stacked and aligned, demosaic and square, color background, levels, curves; bitmap sent to Alan for processing in Photoshop
